BOL LED Driver
Article number:
32.902.0001-0
EAN:
-
Product information "BOL LED Driver"
BOL LED driver 32.902.0001
This LED driver was developed as a component for replacing conventional lighting technologies with more efficient and reliable LED solutions in ovens, microwaves or extractor hoods.
Further technical details on the BOL LED driver can be found in the download area in the data sheet and in the installation guide.
| Application areas: | Home + Professional |
|---|---|
| Efficiency: | 60% |
| Height: | 16,5 mm |
| Lamp: | LED |
| Length: | 70 mm |
| Note warranty conditions: | *Warranty conditions of BJB GmbH & Co. KG as stated as available via the Internet under https://www.bjb.com/en/legal-information/general-terms-and-conditions/ are valid. |
| Operating current: | please refer to the data sheet |
| Operating mode: | Constant current |
| Operating voltage: | please refer to the data sheet |
| Other: | For more information about RoHS/REACH, please refer to: https://www.bjb.com/en/help-service/information-rohs-reach/ |
| Output: | 3 W (± 1 W) |
| Packaging quantity: | 1 |
| Producttype: | LED Oven Lamp |
| Protection class: | Protection class II |
| ROHS REACH Information: | Product contains REACH SVHC: Lead(Pb) in high-melting-point solders, electrical/electronic components made of glass/ceramic (except dielectric ceramic in capacitors, e.g. piezoelectric dev.) and Pb in dielectric ceramic of capacitors ≥125V AC/250V DC |
| Series: | LED |
| Suitable for: | Combined ovens - Microwaves - Pyro - Steam - Cooker Hoods |
| Temperature: | -20 until +85 °C |
| Weight: | 33 g |
| mounting method: | Built-in |
| mounting method 1: | Screw fastening with 2 M4 screws |
| old article number: | 32.902.0001.00 |
